Also need help in assembling u-boot for remote controller
to turn on LE. Tv box mxv+ s905
Posts by KeNt606
-
-
Hello, for a long time absent. Did you use vfd on mxv+ s905?
-
I'm looking for someone with the following boxes: "MXV+ S905" / "M9 Pro" / "CSA93" to test whether the driver will work with i2c based display drivers. Please reply or PM me if you have one of these and can help with testing.
Support was added for the FD650 (actually for TM1650) and for the HBS658 chips.
I have mxv + s905, what should I do?
-
Thanks for the clarification, I hope that everything will turn out all right, and maybe I'll change to boxing with a more functional display
-
I have the MXV + S905. Installed Libreelec 8.90.5 clock on the console did not work.
1. MXV+ S905
2. Amlogic_s905/dtb_file/S905/MXV+ at master · 150balbes/Amlogic_s905 · GitHub
3. gxbb_p200_1G_1Gbit_RealtekWiFi
4. FD650B-S 005CYL0002
-
What issue do you have with WiFi? Any details for "the fix"?
Unfortunately I can not explain, I can only quote the "Hello everyone.
I figured out why T95 wifi slow and does not work with the remote switch. Wifi is slow because it is a bad Chinese cut off IRQ for sdio in meson1.dtb file. patch for it below
--- Meson1.dts.old 2016-05-05 15: 54: 10.000000000 -0400
+++ T95.dts 2016-05-05 16: 19: 08.428008400 -0400
@@ @@ -1173.7 1173.7
dev_name = "aml_newsd.0";
status = "okay";
reg = <0x0 0xd0070000 0x0 0x2000>;
- Interrupts = <0x0 0xd8 0x1>;
+ Interrupts = <0x0 0xd8 0x4>;
pinctrl-names = "sdio_clk_cmd_pins", "sdio_all_pins";
pinctrl-0 = <0x2d>;
pinctrl-1 = <0x2e>;
@@ @@ -1182.7 1182.7
status = "okay";
pinname = "sdio";
ocr_avail = <0x200080>;
- Caps = "MMC_CAP_4_BIT_DATA", "MMC_CAP_MMC_HIGHSPEED", "MMC_CAP_SD_HIGHSPEED", "MMC_CAP_NONREMOVABLE", "MMC_CAP_UHS_SDR12", "MMC_CAP_UHS_SDR25", "MMC_CAP_UHS_SDR50", "MMC_CAP_UHS_SDR104", "MMC_PM_KEEP_POWER";
+ Caps = "MMC_CAP_4_BIT_DATA", "MMC_CAP_MMC_HIGHSPEED", "MMC_CAP_SD_HIGHSPEED", "MMC_CAP_NONREMOVABLE", "MMC_CAP_UHS_SDR12", "MMC_CAP_UHS_SDR25", "MMC_CAP_UHS_SDR50", "MMC_CAP_UHS_SDR104", "MMC_PM_KEEP_POWER", "MMC_CAP_SDIO_IRQ";
f_min = <0x61a80>;
f_max = <0xbebc200>;
max_req_size = <0x20000>;. "Attached is my revised dtb -
Hello, to my mxv + on android 5.1.1 software curtailed speed wifi, it decided corrections dtb.img. Is the fix wifi in LibreElec?
-
1280x1024 is not available in kernel.
It's a pity. Then another question, and it is possible to control an external wifi adapter? And How? may in the future add a menu item.
How to install acestream version 3.1.5 and above? -
Welcome to set LibreElec MXV + and connect the monitor 1280x1024 5: 4 hdmi2dvi, how to set to work correctly? Prefix stretches 720 to 1024, on raspberry pi has a configuration file to configure the resolution and aspect ratio, how to set it here?
