Posts by cartman74

    I tried to re-apply this update under Windows and replace my SSD with the Kodi one. Something strange :


    Under Kodi 19 the device was recognized like this : PVT MATRIX 8*8 on DisplayPort #0 and i lost my Dolby Atmos capabilities.


    Code
    Device 3
        m_deviceName      : hdmi:CARD=PCH,DEV=0
        m_displayName     : HDA Intel PCH
        m_displayNameExtra: PVT MATRIX 8*8 on DisplayPort #0
        m_deviceType      : AE_DEVTYPE_HDMI
        m_channels        : FL, FR, LFE, FC, BC, BL, BR, FLOC, FROC, BLOC, BROC, TFC, TC, TFL, TFR, UNKNOWN1
        m_sampleRates     : 32000,44100,48000
        m_dataFormats     : AE_FMT_RAW,AE_FMT_S32NE,AE_FMT_S16NE,AE_FMT_S16LE,AE_FMT_RAW
        m_streamTypes     : STREAM_TYPE_AC3,STREAM_TYPE_DTSHD,STREAM_TYPE_DTSHD_MA,STREAM_TYPE_DTSHD_CORE,STREAM_TYPE_DTS_1024,STREAM_TYPE_DTS_2048,STREAM_TYPE_DTS_512,STREAM_TYPE_EAC3,STREAM_TYPE_TRUEH


    Then i reboot one more time and my device was GSM LG TV on DisplayPort #0 like before my upgrade.

    Very strange.


    But i still have my Dolby Atmos problem under Kodi 19 ( and 18 too ...)

    Hello !


    I tried the new beta LibreELEC with Kodi 19 on a spare SSD before definitely migrating my NUC.

    I managed to setup my own add-ons with python3 but i still have some audio issue with this Intel NUC Audio driver and linux kernel.


    I have a Sonos Arc soundbar with TrueHD Dolby Atmos capabilities.


    When i launch a sample video with 3 audio tracks, it does not work with the TrueHD sound track but it works with the Dolby Atmos track and the "simple" AC3 5.1.

    If you want to try the file : sample Dolby Atmos


    My logs : (i cut it)


    My audio device :

    Code
         Device 3
             m_deviceName      : hdmi:CARD=PCH,DEV=0
             m_displayName     : HDA Intel PCH
             m_displayNameExtra: GSM LG TV on DisplayPort #0
             m_deviceType      : AE_DEVTYPE_HDMI
             m_channels        : FL, FR, LFE, FC, BC, BL, BR, FLOC, FROC, BLOC, BROC, TFC, TC, TFL, TFR, UNKNOWN1
             m_sampleRates     : 32000,44100,48000,96000,192000
             m_dataFormats     : AE_FMT_RAW,AE_FMT_S32NE,AE_FMT_S16NE,AE_FMT_S16LE,AE_FMT_RAW
             m_streamTypes     : STREAM_TYPE_AC3,STREAM_TYPE_DTSHD,STREAM_TYPE_DTSHD_MA,STREAM_TYPE_DTSHD_CORE,STREAM_TYPE_DTS_1024,STREAM_TYPE_DTS_2048,STREAM_TYPE_DTS_512,STREAM_TYPE_EAC3,STREAM_TYPE_TRUEH
         Device 4


    My sample video file :


    Errors :

    Hello,


    I updated my NUC with the latest Generic x86_x64 image today.


    I lost my video settings and totally lost audio. I think it's the same problem as usual with NUC and DisplayPort/HDMI with Audio and video mixed.


    Everything is now set by default under Video settings : DP1 / 1024X768. And my Audio does not work anymore.


    I found this old trick's post : LibreELEC Testbuilds for x86_64 (Kodi 19.0)


    Code
    echo "blacklist snd_soc_skl" > /storage/.config/modprobe.d/blacklist-snd-soc-skl.conf


    But it didn't work.


    This is my today's log :


    When it worked the last time, it was :
