toam

When I play with my hardwaresetup (see below) videos, no sound comes. The Gui Sounds works and I can play music files without problems.

LibreELEC Alpha 7.90.009 (LibreELEC-RPi2.arm-7.90.009)
Raspberry Pi 3 Modell B
GPU Broadcom Dual Core VideoCore IV, OpenGL-ES 1.1/2.0, Full HD 1080p30
HiFiBerry Amp+ Class-D power amplifier

With LibreELEC 7.0.2 (LibreELEC-RPi2.arm-7.0.2) and the same hardwaresetup it works fine.

Steps:

Add the Device Tree Overlay to config.txt: dtoverlay=hifiberry-amp
Set Audio output device to "ALSA: Default (snd_rpi_hifiberry_amp_Analog)"

I have found that it is exclusively audio streams, which have a higher samplerate than 44100 Hz. Audio tracks in videos with a sampling rate lower than 48000 Hz are output via the HiFiBerry.

More details are available in the Kodi debuglogfile (kodi.log.7z).

Video files examples ("ffmpeg -i videofile"):
Don't work:

Code

vconv version 9.20-6:9.20-0ubuntu0.14.04.1, Copyright (c) 2000-2014 the Libav developers
  built on Dec  7 2016 21:22:31 with gcc 4.8 (Ubuntu 4.8.4-2ubuntu1~14.04.3)
Input #0, matroska,webm, from 'drei_amigos-remastered.mkv':
  Duration: 01:43:09.02, start: 0.000000, bitrate: N/A
    Chapter #0.0: start 0.000000, end 194.194000
    Metadata:
      title           : 00:00:00.000
    Chapter #0.1: start 194.194000, end 678.595000
    Metadata:
      title           : 00:03:14.194
    Chapter #0.2: start 678.595000, end 1109.817000
    Metadata:
      title           : 00:11:18.595
    Chapter #0.3: start 1109.817000, end 1549.214000
    Metadata:
      title           : 00:18:29.817
    Chapter #0.4: start 1549.214000, end 1882.798000
    Metadata:
      title           : 00:25:49.214
    Chapter #0.5: start 1882.798000, end 2450.657000
    Metadata:
      title           : 00:31:22.798
    Chapter #0.6: start 2450.657000, end 2989.904000
    Metadata:
      title           : 00:40:50.657
    Chapter #0.7: start 2989.904000, end 3500.247000
    Metadata:
      title           : 00:49:49.904
    Chapter #0.8: start 3500.247000, end 3754.960000
    Metadata:
      title           : 00:58:20.247
    Chapter #0.9: start 3754.960000, end 4109.522000
    Metadata:
      title           : 01:02:34.960
    Chapter #0.10: start 4109.522000, end 4671.876000
    Metadata:
      title           : 01:08:29.522
    Chapter #0.11: start 4671.876000, end 5046.708000
    Metadata:
      title           : 01:17:51.876
    Chapter #0.12: start 5046.708000, end 5316.853000
    Metadata:
      title           : 01:24:06.708
    Chapter #0.13: start 5316.853000, end 5527.689000
    Metadata:
      title           : 01:28:36.853
    Chapter #0.14: start 5527.689000, end 5961.247000
    Metadata:
      title           : 01:32:07.689
    Chapter #0.15: start 5961.247000, end 6189.024000
    Metadata:
      title           : 01:39:21.247
    Stream #0.0: Video: h264 (High), yuv420p, 720x388, PAR 1:1 DAR 180:97, 23.98 fps, 23.98 tbr, 1k tbn, 47.95 tbc (default)
    Metadata:
      BPS             : 1802830
      BPS-eng         : 1802830
      DURATION        : 01:43:09.016000000
      DURATION-eng    : 01:43:09.016000000
      NUMBER_OF_FRAMES: 148388
      NUMBER_OF_FRAMES-eng: 148388
      NUMBER_OF_BYTES : 1394718584
      NUMBER_OF_BYTES-eng: 1394718584
      _STATISTICS_WRITING_APP: mkvmerge v9.0.1 ('Obstacles') 64bit
      _STATISTICS_WRITING_APP-eng: mkvmerge v9.0.1 ('Obstacles') 64bit
      _STATISTICS_WRITING_DATE_UTC: 2016-11-25 09:59:07
      _STATISTICS_WRITING_DATE_UTC-eng: 2016-11-25 09:59:07
      _STATISTICS_TAGS: BPS DURATION NUMBER_OF_FRAMES NUMBER_OF_BYTES
      _STATISTICS_TAGS-eng: BPS DURATION NUMBER_OF_FRAMES NUMBER_OF_BYTES
    Stream #0.1(ger): Audio: ac3, 48000 Hz, stereo, fltp, 192 kb/s (default)
    Metadata:
      BPS             : 192000
      BPS-eng         : 192000
      DURATION        : 01:43:09.024000000
      DURATION-eng    : 01:43:09.024000000
      NUMBER_OF_FRAMES: 193407
      NUMBER_OF_FRAMES-eng: 193407
      NUMBER_OF_BYTES : 148536576
      NUMBER_OF_BYTES-eng: 148536576
      _STATISTICS_WRITING_APP: mkvmerge v9.0.1 ('Obstacles') 64bit
      _STATISTICS_WRITING_APP-eng: mkvmerge v9.0.1 ('Obstacles') 64bit
      _STATISTICS_WRITING_DATE_UTC: 2016-11-25 09:59:07
      _STATISTICS_WRITING_DATE_UTC-eng: 2016-11-25 09:59:07
      _STATISTICS_TAGS: BPS DURATION NUMBER_OF_FRAMES NUMBER_OF_BYTES
      _STATISTICS_TAGS-eng: BPS DURATION NUMBER_OF_FRAMES NUMBER_OF_BYTES
At least one output file must be specified

Display More

Work:

Code

avconv version 9.20-6:9.20-0ubuntu0.14.04.1, Copyright (c) 2000-2014 the Libav developers
  built on Dec  7 2016 21:22:31 with gcc 4.8 (Ubuntu 4.8.4-2ubuntu1~14.04.3)
Input #0, matroska,webm, from 'piratenkoenigin-1951.mkv':
  Metadata:
    title           : Die Piratenkönigin
    CREATION_TIME   : 2016-11-25T16:29:35Z
    ENCODER         : Lavf55.12.0
  Duration: 01:17:57.24, start: 0.000000, bitrate: N/A
    Stream #0.0: Video: h264 (High), yuv420p, 988x720, PAR 1:1 DAR 247:180, 25 fps, 25 tbr, 1k tbn, 180k tbc (default)
    Stream #0.1: Audio: aac, 44100 Hz, stereo, fltp (default)
    Metadata:
      title           : Stereo
At least one output file must be specified

Display More

dmesg output (dmesg | egrep hifi):

Code

[    4.493188] snd-hifiberry-amp soc:sound: ASoC: CODEC DAI tas5713-hifi not registered
[    4.493199] snd-hifiberry-amp soc:sound: snd_soc_register_card() failed: -517
[    5.564869] snd-hifiberry-amp soc:sound: tas5713-hifi <-> 3f203000.i2s mapping ok

More details are available in the full dmesg output file (dmesg_raspberrypi3.txt).

Thanks for your help.
With friendly greetings from Germany,

toam
